Wall distribution box

Wall distribution boxes in their standard version are electrical equipments of smaller size deigned for placement of devices and other elements of instrumentation and control equipment. They are produced in IP 54 cover.
Wall distribution boxes are manufactured in order to comply with ČSN EN 62208 standards. Operating conditions normal according to the standards. Electrical continuity guaranteed by the conductive part of the cabinet.
R, RP a RN distribution boxes can be delivered empty, with required modifications according to the documents submitted or with the equipment at the customer´s request.



CONSTRUCTION OF DISTRIBUTION BOX

konstrukce rozvodnice

The cabinets are made of self-supportive structure, which is welded from a steel sheet of thickness 1.5 mm. The door opening is provided with a bypass groove fitted with a rubber seal.

The door is made of steel sheet of thickness 1.5 mm. They can be single (standard in the width of 1000 mm) or double, right or left with one lip lock combi- on request EMKA D5 or EMKA butterfly lock on a “fab” key (there are two locks of this kind from the height of 500 mm).The door can be made with vista glass, glued or fitted in EMKA seal ("RP" type).

At the customer´s request, it is also possible to make removable covers for inlet and outlet cables, which are screwed in the top, bottom or side parts of the distribution box.

The box is provided with grounding screws. It is mounted on the wall by four screws (the holes inside the box Ø 10 mm).

A mounting panel with thickness of 2.5 mm is a part of the cabinet, it is made of galvanized metal sheet.

The surface of the switchboard has been treated by high-quality abrasion resistant powder coating komaxit, colour RAL 7032. The switchboard can be delivered also in a different colour shade within RAL scale at the customer´s request.

Nástěnné rozvodnice splňují požadavky technických předpisů a výrobce zaručuje shodu všech výrobků uvedeného typu, uváděných na trh, s technickou dokumentací a požadavky příslušného nařízení vlády.

Wall distribution box with IP 54 cover

Cabinet

  • steel sheet, welded
  • anchor holes Ø 10 mm

Door

  • single (optionally double)
  • one or two locks ( combi, EMKA ...)
  • sealing foam rubber 15 x 10 mm all around the perimeter
  • glass with the RP type (double- layer 6 mm or hardened 4 mm) glued or fitted in the seal.

Surface treatment

  • powder technology, colour shade RAL 7032 structure or different within RAL scale- at the customer´s request.

Mounting panel

  • galvanized metal sheet, thickness 2.5 mm

montážní panel do výšky/šířky 800 montážní panel






kotvící otvory



TYP R

Š

V

H

TYP R

Š

V

H

R 231,5

200

300

150

R 572,5

500

700

250

R 331,5

300

300

150

R 662

600

600

200

R 341,5

300

400

150

R 662,5

600

600

250

R 342

300

400

200

R 682

600

800

200

R 442

400

400

200

R 682,5

600

800

250

R 452

400

500

200

R 683

600

800

300

R 452,5

400

500

250

R 693

600

900

300

R 462

400

600

200

R 6102,5

600

1000

250

R 462,5

400

600

250

R 6122,5

600

1200

250

R 552

500

500

200

R 883

800

800

300

R 552,5

500

500

250

R 8103

800

1000

300

R 562

500

600

200

R 8123

800

1200

300

R 572

500

700

200

R 8153

800

1500

300

Š - width of distribution box, V - height of distribution box, H - depth of distribution box

Remark: These are inner sizes, for the real width and height you have to add 3 mm. The usable depth is H-17 mm. Distribution boxes of non-standard sizes can be made at the customer´s request.





Wall distribution box with IP 54 cover

rozvodnice nerezová RN

RN stainless steel distribution box:

Cabinet

  • brushed stainless steel sheet class 17
  • anchor holes Ø 10 mm

Door

  • single leaf
  • one or two locks EMKA D 5
  • fitting foam seal 15 x 10 mm all around the perimeter

Mounting panel

  • galvanized metal sheet, thickness 2.5 mm





TYP RN

Š

V

H

TYP RN

Š

V

H

RN 341,5

300

400

150

RN 682,5

600

800

250

RN 442

400

400

200

RN 6102,5

600

1000

250

RN 462

400

600

200

RN 883

800

800

300

RN 662,5

600

600

250

RN 8123

800

1200

300

Š - width of distribution box, V - height of distribution box, H - depth of distribution box





Types of locks:

combi crescent lock

zámek kombi půlměsíc

EMKA D5 lock

zámek EMKA D5

EMKA butterfly lock

zámek EMKA motýlkový
